Mount Flame Retardant：UL 94-V2
Mount Temperature Range: -40℃ ~ 85℃
Mount Color: Black / Natural / Other special colors are available
Adhesive Back: 3M 1600-T PE Foam Tape
Green Color - EVA Foam Tape
Other adhesive item # is also available.
Packing: 100pcs/Bag
RoHS Compliant
| DIMESIONS mm(inch) | |||||
| ITEM NO. | Length(L) | Width(W) | Height(H) | Hole | Tie Width (T) |
| GMB-4A | 19.0(0.75) | 19.0(0.75) | 4.2(0.17) | None | 4.0 (0.16) |
| GMB-4AM | 21.8(0.85) | 21.8(0.85) | 4.2(0.17) | None | 4.8(0.19) |
| GMB-4AS | 28.3(1.11) | 28.3(1.11) | 5.7(0.22) | 5.0(0.20) | 5.0(0.20) |
